Select optionsQuick ViewAssembly, Rear End Housing – 60″ GN (1R) – Fully Jigged (STOCK CAR, STREET STOCK, HOBBY STOCK)
$1,542.74 – $1,905.1160″ MAXIMUM aftermarket Ford 9″ housing with new 3″ OD tubes and 2.5″ GN hub snouts.
- Dual internal gusseting provides strongest rear end in the industry.
- Rear ends are straightened after jigging for truer alignment of axles to 3rd member.
- Large 1″ NPT fill plug installed for easy filling or connecting to fill tank.
- Uses a 29.5″ & 32″ length axles.
Assembly includes: 2.5″ MAXIMUM GN hubs, hub bearings, seals, brake rotor, drive flange, axles and all hardware necessary.
Jigged with our:
– Trailing Arm Brackets
– Bushings in Upper Mounts
– Brake Caliper Mounts (GM Metric)– Spring Perches & Shock Mounts (Kit or Welded)
Picture does NOT represent all jig options.
Custom Part is Non-Returnable and Non-Refundable.
Select optionsQuick View -
Add to cartQuick ViewAssembly, Rear End Housing – 60″ GN (L3) w/ Sport Mod Jigged
$1,526.2860″ offset new reproduction stamping Ford 9″ housing with new 3″ tubes and GN hub type snouts. Housings have fill and drain plug installed. Kit includes standard 5×5 GN hubs, hub bearings, seals, brake rotor, drive flange, 31 spline solid axles and all hardware necessary.
Spring Perchs & Brake Caliper Brackets are now Bolt-On Accessories (not included in Rear End Assembly Price)
Add to cartQuick View -
Add to cartQuick ViewAxle, 29.5″ GN Gun Drilled (31 Spline)
$199.5029.5″ Premium GN gun drilled axle.
Add to cartQuick View -
Add to cartQuick ViewAxle, 29.5″ GN Solid (31 Spline)
$94.9929.5″ Premium GN axle.
Add to cartQuick View -
Add to cartQuick View
Axle, 32″ GN Gun Drilled (31 Spline)
$199.5029.5″ Premium GN gun drilled axle.
Add to cartQuick View -
Add to cartQuick View
Axle, 32″ GN Solid (31 Spline)
$94.9932″ Premium GN axle.
Add to cartQuick View -
Add to cartQuick ViewAxles, Non-Floater 30″, 5×4 3/4, (31 Spline)
$325.00These new Currie 31-spline axles feature press in studs in a 5×4 3/4 wheel bolt pattern, , ¼ thick heavy duty bearing retainer plates, and tapered wheel bearings pressed on.
Add to cartQuick View -
Add to cartQuick View
Axles, Non-Floater 30″, 5×5, (28 or 31 Spline)
$325.00These new Superior 28 or 31-spline axles feature screw in studs in a 5×5 wheel bolt pattern, , ¼ thick heavy duty bearing retainer plates, and tapered wheel bearings pressed on.
Add to cartQuick View -
Add to cartQuick ViewBolt On, Caliper Bracket – Small GM (MAXIMUM)
$42.50Bolt On, Caliper Bracket (Small GM)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Caliper Bracket (Small GM) – HEAVY LR (MAXIMUM)
$57.95Bolt On, Caliper Bracket (Small GM)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Clamp – 3″ ID (MAXIMUM)
$55.99Add to cartQuick View -
Select optionsQuick ViewBolt On, Clamp-3″ (Chain Limiter) MAXIMUM
$33.60 – $41.44Bolt On, Clamp-3″ (Chain Limiter)
Select optionsQuick View -
Add to cartQuick ViewBolt On, Clamp-3″ Chain Limiter w/ Chain and Adjuster Kit
$107.46Bolt On, Clamp-3″ Chain Limiter w/ Chain and Adjuster Kit
Add to cartQuick View -
Add to cartQuick ViewBolt On, Spring Perch – Center (MAXIMUM)
$45.86Bolt On, Spring Perch Center
Add to cartQuick View -
Add to cartQuick ViewBolt On, Spring Perch – Offset (MAXIMUM)
$45.86Bolt On, Spring Perch Offset
Add to cartQuick View -
Select optionsQuick ViewBolt On, Suspension Kit
$461.68 – $640.91Bolt On Suspension Kit Stock Car
Select optionsQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket – XTREMER – LR ONLY (MAXIMUM)
$125.00Bolt On, Trailing Arm Bracket Kit – XTREMER LR
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – LH – Mod Lite (MAXIMUM)
$69.00LH Mod Lite trailing arm bracket with integrated brake caliper mount.
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – RH – Mod Lite (MAXIMUM)
$69.00RH Mod Lite trailing arm bracket with integrated brake caliper mount and shock/coilover mounts.
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – 2.5″ SINGLE HOLE (MAXIMUM)
$145.00Bolt On, Trailing Arm Bracket Kit – (2.5″ SINGLE HOLE)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – 2.5″ SLOTTED (MAXIMUM)
$185.00Bolt On, Trailing Arm Bracket Kit – (2.5″ SLOTTED)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – 3.5″ SLOTTED (MAXIMUM)
$240.00Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – Extreme Drop (MAXIMUM)
$174.66Bolt On, Trailing Arm Bracket Kit Extreme Drop LR
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – HEAVY, Single Hole Kit (MAXIMUM)
$259.95Bolt On, Trailing Arm Bracket Kit – HEAVY, Single Hole (Kit)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – HEAVY, Single Hole LR ONLY (MAXIMUM)
$156.00Bolt On, Trailing Arm Bracket Kit – HEAVY, Single Hole (LR Only)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – HEAVY, Slotted Kit (MAXIMUM)
$259.95Bolt On, Trailing Arm Bracket Kit – HEAVY, Slotted (Kit)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – HEAVY, Slotted LR ONLY (MAXIMUM)
$156.00Bolt On, Trailing Arm Bracket Kit – HEAVY, Slotted (LR Only)
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – Multi Hole (MAXIMUM)
$146.66Bolt On, Trailing Arm Bracket Kit Multi Hole
Add to cartQuick View -
Add to cartQuick ViewBolt On, Trailing Arm Bracket Kit – XTREMER KIT (MAXIMUM)
$205.95Bolt On, Trailing Arm Bracket Kit – XTREMER
Add to cartQuick View -
Add to cartQuick ViewBOLT, TRAILING ARM (1/2″-13) (METRIC FRAME)
$18.00This 1/2″-13 threaded bolt extends the hex end of the bolt out of the frame rail, allowing you to remove the bolt without losing your socket or fighting the frame rail.
Add to cartQuick View -
Add to cartQuick ViewBolt, Weight Jack – 11″ Long
$21.991 diameter x 11 long weight jack bolt. (1″-8 Coarse Thread)
Add to cartQuick View -
Add to cartQuick ViewBRACKET, 3 LINK, NSM MOD, BOLT ON – LH (MEDIEVAL ONLY 2016-2018)
$50.00BRACKET, 3 LINK, NSM MOD, BOLT ON – LH (MEDIEVAL ONLY 2016-2018)
Add to cartQuick View -
Add to cartQuick ViewBRACKET, 3 LINK, NSM MOD, BOLT ON – RH (MEDIEVAL ONLY 2016-2018)
$50.00BRACKET, 3 LINK, NSM MOD, BOLT ON – RH (MEDIEVAL ONLY 2016-2018)
Add to cartQuick View -
Add to cartQuick ViewBracket, Caliper (Small GM)
$11.20These caliper mount brackets are built to fit the small GM metric calipers. Use this kit to build your own custom rear end.
(Sold Individually)Add to cartQuick View -
Add to cartQuick ViewBracket, Caliper (Small GM) HEAVY (LR)
$39.95This caliper mount brackets is built to fit the small GM metric calipers.
Made out of 1/2″ thick steel to gain extra LR weight.
(Sold Individually)
Add to cartQuick View -
Add to cartQuick ViewBRACKET, CHASSIS PANHARD, BOLT ON – 3 INCH OFFSET (PAIR)
$50.00BRACKET, CHASSIS PANHARD, BOLT ON – 3 INCH OFFSET (PAIR)
Add to cartQuick View -
Add to cartQuick ViewBRACKET, TRAILING ARM (MULTI-HOLE) – RR ONLY
$50.00RR multi hole trailing arm bracket only.
Add to cartQuick View -
Add to cartQuick ViewBRACKETS, TRAILING ARM – 2.75″ (CRUSA)
$60.00Designed for the CRUSA stocks, these trailing arm brackets have the lowest mounting hole position possible. 2.75″ from axle tube to center of hole.
(Sold as a Pair)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm – HEAVY, Slotted (Kit)
$199.95Designed for stock cars with a 7.5″ max trailing arm length.
These trailing arm brackets use common offset slugs (sold separately) to allow you to change the amount of lead or trail in the rear end. Simply replace the slug with different combination of offset slugs. Tack weld the slugs to secure them to the trailing arm.
This bracket is also built heavy, weighs 7.5lbs (with slugs) to help increase LR rear end weight.
Will increase drive and adjustability.
(Sold as a pair)
(Slugs sold separately)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm – HEAVY, Slotted (LR ONLY)
$100.00Designed for stock cars with a 7.5″ max trailing arm length.
This trailing arm bracket use common offset slugs (sold separately) to allow you to change the amount of lead or trail in the rear end. Simply replace the slug with different combination of offset slugs. Tack weld the slugs to secure them to the trailing arm.
This bracket is also built heavy, weigh 7.5lbs (with slugs) to help increase LR rear end weight.
Perfect for the guys that already have or Extreme or Xtrmer Drop brackets. Simply replace the LR bracket and have increase drive and adjustability.
(Sold individually)
(Slugs sold separately)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm – Slotted (Single Hole @ 2.5″)
$125.002.5″ drop trailing arm brackets slotted to accept offset slugs. Change your lead or trail of the rear end by simply changing the combination of offset slugs.
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm – Slotted (Single Hole @ 4.0″)
$125.004.0″ drop trailing arm brackets slotted to accept offset slugs. Change your lead or trail of the rear end by simply changing the combination of offset slugs.
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm (Extreme Drop)
$112.00Looking for increased forward bit and traction? Then this trailing arm bracket kit is a must have.
Specifically designed to increase LR drive off the corner and corner entry adjustability with multiple hole adjustments on the RR.
LR bracket is 6.75″ from axle tube to center of bottom hole. (USRA/IMCA Stock Car Legal)
(Sold as a Pair)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm (Hobby Stock)
$50.40Designed for the Hobby stocks, these trailing arm brackets have the lowest mounting hole position possible. 2.50″ from axle tube to center of hole.
(Sold as a Pair)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm (Multi-Hole)
$84.00This trailing arm bracket kit was designed to allow trailing arm angle adjustments just like what can be done on modifieds…..
(Sold as a Pair)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm (Single Hole)
$50.40Designed for the Wissota street stocks, these trailing arm brackets have the lowest mounting hole position possible. 4.0″ from axle tube to center of hole.
(Sold as a Pair)
Add to cartQuick View -
Add to cartQuick ViewBrackets, Trailing Arm (XTREMER)
$139.00Looking for that edge over everyone else…. Then this NEW trailing arm bracket kit is a must have.
Specifically designed to increase LR drive off the corner and corner entry adjustability with multiple hole adjustments on the RR.
LR bracket is 7” from axle tube to center of bottom hole, but still conforms to the 7.5″ max length rules. (USRA/IMCA Stock Car Legal)
(Sold as a Pair)
Add to cartQuick View -
Add to cartQuick ViewBushing Washer – Rear Trailing Arms
$4.50If you are racing on a rough track or up against the cushion you will need these bushing washers to help hold the rubber from pushing out the end of the bushing housing.
Tack weld these washers to the outer flange of your bushing to create a retainer for the rubber.
SOLD as a PAIR
Add to cartQuick View -
Add to cartQuick ViewBushing, “PULL” (Trailing Arms)
$30.75This is a new bushing that is used in the upper & lower trailing arms to create side bite and cushioning of the rear end.
Sold individually
Add to cartQuick View -
Add to cartQuick ViewBushing, “PULL” with Washer (Trailing Arms)
$31.75This is a new bushing that is used in the upper & lower trailing arms to create side bite and cushioning of the rear end.
Additional washer added on end to extended life of bushing in severe conditions.
Sold individually
Add to cartQuick View -
Add to cartQuick ViewBushing, “SPHERICAL” – Trailing Arm (MAXIMUM)
$44.95MAXIMUM Spherical Bushing
Sold individually
Add to cartQuick View -
Add to cartQuick ViewClamp, Limit Chain (1-1/2” Tube) – Wehrs
$25.001-1/2” Tube Diameter Clamp For Limit Chains on Chassis Side
Add to cartQuick View -
Add to cartQuick ViewClamp, Limit Chain (1-3/4” Tube) – Wehrs
$25.001-3/4” Tube Diameter Clamp For Limit Chains on Chassis Side
Add to cartQuick View -
Add to cartQuick ViewCup, Spring – Tapered
$13.38These tapered profile spring cups are manufactured from high strength steel and are designed to minimize any stretch and bending while still being lightweight. Has a 1/4″ hole on bottom to allow bolting to your weight jack bolt.
Add to cartQuick View -
Add to cartQuick ViewCup, Spring – Tapered Extended (LR)
$22.34These tapered profile spring cups are manufactured from high strength steel and are designed to minimize any stretch and bending while still being lightweight. Has a 1/4″ hole on bottom to allow bolting to your weight jack bolt. This Spring Cup is extended to hold the spring while the chassis hikes for Northern Sport Mods and Limited Mods.
Add to cartQuick View -
Add to cartQuick ViewDecal Package
$9.95Add to cartQuick View -
Select optionsQuick ViewGift Certificate
$25.00 – $100.00Select optionsQuick View -
Select optionsQuick ViewHousing, Rear End – 60″ GN (1R) – Fully Jigged (STOCK CAR, STREET STOCK, HOBBY STOCK)
$768.80 – $918.1560″ GN 1R offset MAXIMUM aftermarket Ford 9″ housing with new 3″ OD tubes and 2.5″ GN hub snouts.
- Dual internal gusseting provides strongest rear end in the industry.
- Rear ends are straightened after jigging for truer alignment of axles to 3rd member.
- Large 1″ NPT fill plug installed for easy filling or connecting to fill tank.
- Uses a 29.5″ & 32″ length axles.
Jigged with our:
– Trailing Arm Brackets
– Bushings in Upper Mounts
– Brake Caliper Mounts (GM Metric)– Spring Perches & Shock Mounts (Kit or Welded)
Picture does NOT represent all jig options.
Custom Part is Non-Returnable and Non-Refundable.
Select optionsQuick View -
Add to cartQuick View
Housing, Rear End – 60″ GN (L3) w/ Sport Mod Jigged
$889.2060″ offset new reproduction stamping Ford 9″ housing with new 3″ tubes and GN hub type snouts. Housings have fill and drain plug installed. SportMod jigged.
Spring Perchs & Brake Caliper Brackets are now Bolt-On Accessories (not included in Rear End Housing Price)
(IMCA Legal)
Custom Part is Non-Returnable and Non-Refundable.
Add to cartQuick View -
Select optionsQuick ViewHUB ASSEMBLY – 2.5″ GRAND NATIONAL
$253.99 – $255.99Sold individually
Select optionsQuick View
